TYM T723 - Page 27

Inspection
items
Daily
Inspection and servicing intervals
Hour of operation
(X10 on hour meter)
Intervals after that
Judgment
criteria
mm(in)
5 1
0
1
5
2
0
2
5
3
0
3
5
4
0
4
5
5
0
5
5
6
0
Transmission
oil
○
● ●
Every 500 hours or
12months
after first 50 hours
Clutch pedal
free play
○
Check daily Free Play:20 to
30mm
Brake pedal
free play
○
Check daily Free Play:30 to
40mm
Brake
performance
○
Check daily Interlocked brakes
should work
simultaneously
Lever
performance
○
Check daily Every lever should
work positively
Steering
wheel free
play
○
Check daily About 50mm (1.97)
on circumstance
Toe-in
★ ★
Check after every 300
hrs
0 to 4 mm (0~0.157
in)
Retightening
ball joints of
steering
system
○ ○ ○
Check after every 300
hrs
Wheel
tightening
bolts and nuts
○
Check daily All should be tighten
Front:116-130(ft-lbs)
Rear:268-282(ft-lbs)
Greasing each
nipple
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Replenish every 50 hrs
(Everyday in dusty
condition)
Loose bolts
and nuts
○
All should be tighten
Electric
wiring
○ ○ ○
Check every year All should work
properly.
○ inspection,replenish,and adjustment
● Replacement △ Cleaning and/or washing
★ Consult your Dealer
☞ TRANSMISSION
1-26
