your position is our focus
Good
GND
Microstrip
GND
RF
_IN
Antenna Supply Voltage
(e.g. VCC_RF)
Inductor L
GND
GND
Inductor L
Microstrip
RF
_IN
Antenna Supply Voltage
(e.g. VCC_RF)
Bad
Figu
re 47: Recommended layout for connecting the antenna bias voltage for LEA-4M and NEO-4S
GPSModules-SystemIntegrationManual(SIM)(incl.ReferenceDesign) Design-In
GPS.G4-MS4-05007-A1
Page 58
