7.2.1 Using u-center Message View
The u-center Message View is used to communicate with the GPS receiver. Receiver output messages (e.g.
navigation output, status and debug information) are displayed; input messages (e.g. configuration messages)
canbesent.TherearedifferentsectionsforNMEAandUBXprotocol.
Message Display
Displaysthemes-
sagecontent.
Figure 111: u-Center Message View
Element Name Description
Lock
PreventstheMessageViewfrombeingupdatedwithnewdata
whenlocked.
ClearAll ErasestheentireMessageView.
Send SendsthecurrentmessagetotheGPSreceiver.
Poll Polls theselectedmessageonce.
Autopoll Automaticallypollsanewlyselectedmessageonce
MessageHotkey Assignsahotkeytotheselectedmessage
Table 55: Buttons description in the U-center Message View
Hex Dump
Displaysthemes-
econtentin
xadecimaland
sag
he
ASCIIform.
Message Tree
AlistofallNMEA
andUBXmessage
T
oo
l
ba
r
GPSModules-SystemIntegrationManual(SIM)(incl.ReferenceDesign) PCSupportTools
GPS.G4-MS4-05007-A1
Page 139
