Universal APX 525 - Page 128

APX 525/625 Generator Revision C Service Adjustments
© 2005 Del Medical Imaging Corporation
7/5/2005 Page 119
Figure 61 – mAs Regulator Board
(
To
p
of board
)
GND Test
Point
Exposure
Start (high)
(TP1)
mAs Ad
j
ust
mAs Adjust
(
Short time
)
mAs Pulses
(
TP3
)
Serial Data
(
TP4
)
mA IN
(
TP5
)
mAs Stop (high)
(
TP2
)
