APX 525/625 Generator Revision C Pre-Installation
© 2005 Del Medical Imaging Corporation
7/5/2005 Page 54
Connection Information for K
it 636-0070P1 –
For 40kW 208 V Applications only
Schematic - #636-0070P1 – Three Phase Line Matching Transformer
For 40kW 208 VAC Applications Only
190
V
208 V
240
V
260
V
280
V
190 V
208 V
240
V
260
V
280
V
190
V
208 V
240
V
260
V
280
V
Three Phase
Output to
TB1
Three Phase
Output to
TB1
Three Phase
Output to
TB1
Single Phase
Output to
TB1
