Figure 3-21. FenwalNET 8000-ML Set Menu Functions (Cont’d - Fig. 5 of 14)
FOOTNOTES (Figure 3-21):
14 Registration. Manually Register SLC Devices.
Purpose: The FenwalNET 8000-ML control unit needs to know which SLC addresses (of the 255
possible addresses) will be occupied by a SmartOne detector, monitor module, relay module or
control module. The Registration Procedure enters an occupied address into the control-unit's
configuration memory for each SLC device that it encounters during execution. The SLC devices must
be uniquely addressed prior to execution of the Registration Procedure.
The SLC devices are assigned the following default-operating parameters:
SLC Device Default Operating Parameters
Ionization Detectors 0.8% per foot Pre-alarm Threshold
1.0% per foot Alarm Threshold
Latching Operation
Activates General-Alarm List
Photoelectric Detectors 1.5% per foot Pre-alarm Threshold
2.0% per foot Alarm Threshold
Latching Operation
Activates General-Alarm List
Heat Detectors 120°F Pre-Alarm Threshold
135°F Alarm Threshold
Latching Operation
Activates General-Alarm List
ITLCO/CTLCO Off
Monitor Modules (AIs) Alarm-Initiating Device
Latching Operation
Activates General-Alarm List
3. SET
3. SLC Devices
Cont’d
*
3. Registration
Device Registration
SLC Devices From*__ to __
 (1-255)
4. De-Registration
Device De-Registration
SLC Devices From*__ to __
 (1-255)
5. Blink Control
*= Level-2 (Installer) Password required .
14
15
SLC Module Selection
Enter SLC Module Number (1-8):_*
Program Device Blink Control
SLC Devices From*__ to __
 (1-255)
Set Blink Control
1: Blink Off 2: Blink On *

16, 17
SLC Module Selection
Enter SLC Module Number (1-8):_*
SLC Module Selection
Enter SLC Module Number (1-8):_*
