multiMATIC 700/2
Notes
10/2015 50 Training 0020228700_00
Prompt
Select
Comment
Day temp. cooling
15.0–30.0 °C
Displays the current target value for the room temperature
during cooling
Set-back temp.
heat.
5.0 – 30.0 °C
Displays the current target value for the room temp.
Room temperature
Display in °C
Display only for wall-mounted controllers
Ventilation
Air quality sensor 1
Display in ppm
Only in conjunction with recoVAIR .../4
Air quality sensor 2
Display in ppm
Exhaust air humidity
Display in %
Yield/consumption display
The graphic display provides an overview of the controller's yield/consumption over a
maximum of two years. The total yield/consumption is continuously updated, and the
monthly yield/consumption bar and its display at the top right are updated every day at
00:00. To reset the total yield/consumption, go to "System status".
The calculated solar yield of the VPM S, VPM D, VMS and auroSTEP plus is
also transferred to the VRC 700.
Solar yield / environmental yield / electrical consumption /
fuel consumption / heat recovery
Key:
1
Controller
2
Highest monthly yield/consumption
3
Total yield/consumption since reset
4
Yield/consumption graph for the
previous year
5
Yield/consumption graph for the
current year
1
2
3
5
4
