Vaillant MultiMatic 700/2 - Summary of Level Structure

multiMATIC 700/2
Notes
10/2015 80 Training 0020228700_00
4.5.8 Summary of level structure
Installer level
Information
Desired temperatures
Time programmes
Days away from home
scheduling
Days at home scheduling
Basic settings
Level 2:
Simple
controller configuration
Level 3
Level 1:
Setting the
desired temperature
Ventilation boost
Cylinder boost
*5
System OFF active
Heating
*1
Hot water
*4, *5
Manual cooling
*6
1 day at home
1 day away from
home
Party function
*1)
Off, Auto, Day, Set-back
*2)
Off, Auto, Day
*3)
Auto, Day, Set-back
*4)
Off, Auto, Day
Cooling
*2, *6
Ventilation
*3
Ventilation stage
*6
= Displayed if "Cooling possible" = "Yes" is selected in the system configuration
= Displayed in conjunction with recoVAIR .../4
*5
= Displayed if "Cylinder" = "active" is selected in the system configuration
Auto
13.5 °C
11:54
23.0 °C
Desired heating temp. 23.0 °C
Menu
Op. mode
