Type of circuit
Setting the type of circuit has an effect on the parameters displayed for the heating cir-
cuits, the zones, and on the VRC 700's control strategy. The following provides an
overview of which parameters are displayed in the system configuration:
Setting
Parameters displayed in the "Heating circuit 1/2/3" sub-menu
Inactive
None
Heating
Status
Cooling possible
Target flow temp.
Room temp. mod.
Current temperature (heating circuit 2 only)
Dew point monitoring
Excessive temp. (heating circuit 2 only)
Min. cool. fl. tgt temp.
Max limit outs.temp.
Cooling start temperature
Heating curve
Offset dew point
Minimum temperature
Status ext. heat dem.
Maximum temperature
Pump status
Auto Off mode
Mixer status (heating circuit 2 only)
Fixed value,
Pool
Status
Maximum temperature
Target flow temp.
Target flow temp.: Day
Current temperature (heating circuit 2 only)
T.fl.temp.: Set-back
Excessive temp. (heating circuit 2 only)
Status ext. heat dem.
Max limit outs.temp.
Pump status
Minimum temperature
Mixer status (heating circuit 2 only)
DHW
Target cylinder temp.
Pump status
Ret.fl.incr.
Target return temp.
Mixer status (heating circuit 2 only)
