Vaillant MultiMatic 700/2 - Heat Generator 1; Heat Generator 2; Heating Circuit 1; 2; 3

multiMATIC 700/2
Notes
10/2015 65 Training 0020228700_00
4.5.7.4 Heat generator 1
Prompt/setting
Select
Comment
Status
Standby, Heat. mode,
Cooling, DHW
Current flow temp.
Display in °C
Displays the flow temperature measured by the
flow temperature sensor inside the unit. If an
external sensor has been fitted, the tempera-
ture it is measuring is displayed here.
4.5.7.5 Heat generator 2
Prompt/setting
Select
Comment
Status
Standby, Heat. mode,
Cooling, DHW
Current flow temp.
Display in °C
Displays the flow temperature measured by the
flow temperature sensor inside the unit. If an
external sensor has been fitted, the tempera-
ture it is measuring is displayed here.
4.5.7.6 Additional module
Prompt/setting
Select
Comment
Status
Standby, Heat. mode,
Cooling, DHW
Only in conjunction with aroTHERM and
flexoTHERM
4.5.7.7 HEATING CIRCUIT 1 / 2 / 3
Prompt/setting
Select
Comment
Type of circuit
Inactive, Heating,
Fixed value, DHW,
Ret.fl.incr., Pool
Selects the type of circuit
Status
Standby, Heat. mode,
Cooling, DHW
Target flow temp.
Display in °C
Displays the target value for heating circuit
1/2/3
Current temperature
Display in °C
Only for heating circuit 2 and 3, heating
circuit 1 with VR 70 = 3, 5, 12 (mixer circuit)
or VR 71
Excessive temp.
0 – 30 K
Sets the excess temperature for the heat gen-
erator
Only for heating circuit 2 and 3, heating
circuit 1 with VR 70 = 3, 5, 12 (mixer circuit)
or VR 71
Max limit outs.temp.
10 – 99 °C
Setting the outside temperature at which heat-
ing mode remains permanently switched off
