3. Lead the sensor cable through the connector cover, and attach the cable to the probe.
4. Loosen the compression fitting with your fingers and insert the probe inside the ring.
Pay attention to the rubber insert.
1 Compression fitting
2 Rubber insert
Chapter 11 – Sensor Installation to Sensor Support Arm
111
