MM101 – D-4E HOT MELT UNIT 21
VALCO MELTON S.L.U. Pol. Ind. Agustinos C/G 34 3116 0 ORCOYEN, NAVARRA
TEL: +34 948 321580 Fax: +34 948 326584 melton@melton.es www.valcomelton.com
5. Attach this end of the glue hose to the fluid outlet fitting in
the manifold (Figure 5-2).
6. Using two wrenches, one on the fluid outlet fitting and the
other on the hose swivel nut, connect hose ‘one’ to fluid
outlet port ‘one’ of the machine.
7. Connect the lead assembly’s male electrical connector to
the electrical receptacle located on the back panel above
the fluid outlet ports. Connections are shown in Figure 5-2
The left fluid outlet port should be
used first to prevent trapped hot melt
adhesive from charring in the lower
portion of the manifold
Straight fittings are standard but
other fittings are available from Valco
Cincinnati (see Section 10—Part
Number List).
The use of two wrenches prevents
the hose from twisting inside while it
is being tightened.
The use of two wrenches prevents
the hose from twisting inside while it
is being tightened.
