Varec 2500 - 2500 ATG Product Dimensions

2500 Automatic Tank Gauge
104 Installation and Operations Manual
2500 ATG Product Dimensions
Figure 28: 2500 ATG Product Dimensions
3.2"
(82 mm)
2.0"
(51 mm)
3.5"
(89 mm)
4.0"
(101 mm)
5/16"-18x1
3.0" (76 mm)
1.28"
(32 mm)
5/16"-18x1.125
5.4"
(137 mm)
8.5"
(216 mm)
3/8" NPT
2.2"
(56 mm)
0.6"
(15 mm)
5.8"
(147 mm)
1-1/2" NPT
1/2" NPT
5.5"
(140 mm)
8.7"
(221 mm)
13.6"
(345 mm)
11"
(279 mm)
3.2"
(82 mm)
3.5"
(89 mm)
4.0"
(101 mm)
5.4"
(137 mm)
0.6"
(15 mm)
5.8"
(147 mm)
1-1/2" NPT
1/2" NPT
5.5"
(140 mm)
8.7"
(221 mm)
13.6"
(345 mm)
11"
(279 mm)
1-1/2" NPT
Type B Gaugehead
Type C Gaugehead
