2500 Automatic Tank Gauge
92 Installation and Operations Manual
Additional items
When performing a complete overhaul or refurbish, Varec recommends replacement of the
tape (or tape and cable combination), anchors, and guide wires as shown in the following
table.
Table 7: Additional Items Recommended for Tank Overhaul List
Shoulder Bushing Retrofit Kit
The Shoulder Bushing Retrofit Kit provides the parts required to replace the shoulder bushings
on the 2500 ATG.
Item Part No. Description
AA BM5478-600 Tape Clamp Assembly
BB A371-046 Cover Gasket (sheave elbow)
JJ P31-150 Elbow Bolt
KK A370-006 Elbow Yoke
EE B7650-606 Tape - Imperial (Length 136'), (316 SS) for a tank 60 ft high
B7650-306 Tape - Imperial (Length 80'), (316 SS) for a tank 32 ft high
B9736-606 Tape - Metric (Length 41.25 m), (316 SS) for a tank 18.29 m high
B9736-306 Tape - Metric (Length 24.38 m), (316 SS) for a tank 9.75 m high
FF B7678-606 Tape and Cable (Ø 3/32”) Combination -
Imperial (Length 133') for a tank 60 ft high
B7678-306 Tape and Cable (Ø 3/32”) Combination -
Imperial (Length 73') for a tank 30 ft high
B13982-606 Tape and Cable (Ø 3/32”) Combination -
Metric (length 44.5 m) for a tank 18 m high
B7678-106 Tape and Cable (Ø 3/32”) Combination -
- Imperial (Length 73') for a tank 30 ft high
B13982-606 Tape and Cable (Ø 3/32”) Combination -
Metric (Length 22.2 m) for a tank 9 m high
GG BM5200 Top Anchor - welded, (Steel)
BM5088 Top Anchor - welded, (316 SS)
BM3646 Top Anchor, (150# Steel)
BM3647 Top Anchor, (300# Steel)
HH B10543-306 Guide Wire Tank Height 32 ft.
B10543-606 Guide Wire Tank Height 60 ft.
Part No. Description
13-09794-00 Shoulder Bushing Retrofit Kit
