2500 Automatic Tank Gauge
84 Installation and Operations Manual
Basic Maintenance Kit
The Basic Maintenance Kit provides all the parts required for basic maintenance on the 2500
ATG. Depending on your selection, you will receive the metric or imperial parts required.
Table 4: Basic Maintenance Kits and Parts Numbers List
Part No. Description
13-08766 Basic Maintenance Kit - Imperial
13-08767 Basic Maintenance Kit - Metric
Item Part No. Description Quantity in Kits
1
B4396-046 Back Cover Gasket
2500A (Prior to 1983)
1
02-04490-071 Back Cover Gasket
2500B (1983 - 2012)
1
02-013127-046 Back Cover Gasket
2500C (2013 and later)
1
4 B7415-093 Teflon Washer 1
5 B8235-040 Imperial Dial Gear 1 (Imperial kit only)
5m B8327-040 Metric Dial Gear 1 (Metric kit only)
6 02-013187-046 Counter Cover Gasket 1
7 B8218-001 Imperial Dial (Fractional or Decimal) 1 (Imperial kit only)
7m B8325-001 Metric Dial 1 (Metric kit only)
15 B7796-005 Gauge Check Spring 1
16 B6547-005 Tape Keeper Post 1
21 BM18849-100 Imperial Counter Assembly 1 (Imperial kit only)
21m BM18850-100 Metric Counter Assembly 1 (Metric kit only)
23 P10-2 Retaining Ring 4
24 P25-16 Pinion Gear 1
25 B7300-005 Tape Keeper Spring 1
27 P31-669 Binding Head Mach. Screw 1
40 P031-01-1719 Binding Head Mach. Screw 3
43 P031-08-1720 Counter Screw 3
44 P31-1 Washer 6
45 P31-13 Shim Washer 18
55 02-09598 Shoulder Bushing 4
56 B14872-101 Motor Top Plate 1
62 B7795-005 Hair Pin Spring 1
72 P031-29-1883 Slotted Shim (not shown) 1
