Varec 2500 - Negator Cassette and Negator Cassette Kit

Varec, Inc. 93
Table 8: Shoulder Busing Kit and Individual Parts List
Figure 20: 2500 ATG (Type C Gauge Head Shown) Shoulder Bushing Retrofit Kit Parts Diagram
Negator Cassette and Negator Cassette Kit
The Negator Cassette Kit (item 68) provides the parts required to convert a 2500 ATG fitted
with a negator motor to a gauge head with a negator cassette.
Item Part# Description QTY
23 P10-2 Retaining Ring 4
44 P31-1 Washer 2
45 P31-13 Shim Washer 6
55 02-09598 Shoulder Bushing 4
56 B14872-101 Motor Top Plate 1
72 P013-29-1883 Slotted Shim 1
Part No. Description
44
23
45
55
Item Part# Description QTY
50 06-10368 Negator Cassette only na
68 13-10652 Negator Cassette kit na
Item Part# Description QTY
