Varec, Inc. 59
Chapter 6
Gauge Head Disassembly and Re-
assembly
Use of the maintenance kits requires that the user understand the disassembly and
reassembly of the gauge head to replace parts.
Gauge Head Disassembly
Figure 8 is key to understanding the disassembly/reassembly procedure. The small numbers in
parentheses (for example,
(12)), refer to the item numbers in this figure. References in the
following procedures are directed to this figure, unless otherwise indicated.
