2500 Automatic Tank Gauge
106 Installation and Operations Manual
Table 16: Conduit Elbows
Standard Installation Kits
Table 17: Standard Installation Kits
Oil Seals
Table 18: Oil Seals
06-08564 90° Elbow Atmospheric Aluminum Delrin
06-07726 90° Elbow Atmospheric Aluminum 316 SS
BM4675 90° Elbow Atmospheric Cast iron 316 SS
BM5074 90° Elbow Atmospheric 316 Stainless steel 316 SS
BM3480 135° Elbow Atmospheric Aluminum Delrin
BM3481 180° Elbow Atmospheric Aluminum Delrin
BM3621 NA Tape carrier Atmospheric Aluminum Delrin
Description Standard Moderate Severe Extreme (NaOH) Extreme (H2SO4)
Gauge Head Aluminum Aluminum Cast iron Cast iron Cast iron
Elbow assembly Aluminum 316 S.S. Cast iron Cast iron Cast iron
Top anchors Steel 316 S.S. Steel Steel Stl/Alloy 20
Guide Wire weight Steel 316 S.S. 316 S.S. Monel Alloy 20
Guide Wires 316 S.S. 316 S.S. 316 S.S. Monel Alloy 20
Perforated tape 316 S.S. 316 S.S. 316 S.S. Monel Alloy 20
Standard float 316 S.S. 316 S.S. 316 S.S. Monel Alloy 20
Part # Material Oil seal
10-01994-AAA Aluminum 8.5" (216mm) Water column operating pressure
10-01994-BAA Cast iron 8.5" (216mm) Water column operating pressure
10-02861-AAA Aluminum 27" (686mm) Water column operating pressure
