2500 Automatic Tank Gauge
22 Installation and Operations Manual
Figure 2: Cone Roof Tank with Internal Pan (Floating Roof)
Figure 3: Bolted Cone Roof Tank
14.50
[368 ]
1-1/2 Inch pipe and fittings
furnished by customer
Tank
roof
Cable guide and
well furnished
by customer
4
2
3
Remove float guide eyes
if necessary
12 [305]
Minimum with
float at product
level
18.25 [464]
Over guide eyes
ø
12-24 [305-610]
With float at bottom
of well
.25
[6]
24.00
[610]
Suggested
8
Typical
View C - C
Pipe Support
Bracket Detail
6.00 [152 ]
Convenient
eye level
1
Grad e
Layout for pipe supports
spaced approximately at
10 foot [3 meter] intervals
5
8.00
[203]
Maximum
36.00
[914 ]
16.00
[406 ]
Minimum
.25
[6]
.25
[6]
Typical
1-1/2 Inch NPT union
recommended
4.50
[114 ]
CC
4.50
[114]
1. Gaugehead
2. Float
3. Tape
4. Tape/Cable fastener
5. Pipe Support Bracket
8. Sheave elbow
Unless otherwise noted
dimensions in inches (millimeters).
All welding by customer.
Note Installation hatch not shown.
Varec recommends installing
a installation hatch.
1-1/2 inch NPT coupling
furnished by customer
1
[25]
Standard
roof pitch
Tank
roof
12
[305]
17.00
[432]
9
ø
14.50
[368]
3
2
4
C
Maximum
36.00
[914]
16.00
[406]
Minimum
1-1/2 Inch pipe fittings
furnished by customer
6
11
8
F
Support bracket
mounting hardware
(ø 1/2 [12]) furnished
by customer
Grade
Convenient
eye level
1
View C - C
Bracket detail
C
7.88
[200]
F
15.75
[400]
View F - F
2[51] X 2[51] X .25[6.4]
Steel angle
4.50
[114]
4.50
[114]
10
5
1-1/2 Inch NPT union
recommended, furnished
by customer
16.62
[422]
1. Gaugehead
2. Float
3. Tape
4. Tape/Cable fastener
5. Pipe Support Bracket
6. Top Anchor
7. Bottom Anchor
8. Sheave elbow
9. Float Guide Cable
10. Upper support Bracket
11. Deck Flange
Unless otherwise noted
dimensions in inches (millimeters).
All welding by customer.
Note Installation hatch not shown.
Varec recommends installing
a installation hatch.
17.00
[432]
8.50
[216]
Ø 2.00 [51] hole with
4X Ø .56 [14] holes on
Ø 3.50 [89] B.C.
[3 places]
