2500 Automatic Tank Gauge
74 Installation and Operations Manual
8 BA7761 Tape Storage Sheave Assembly (Includes item57)
BA9796 Crank Tape Storage Sheave
06-10364 Tape Storage Sheave Assembly - Cassette
9 B8234-001 Dial Retainer
10 B7693-005 Shaft (2) - Gauge Head Type B
BA7763 Shaft Support Assembly - Gauge Head Type C and Cast Iron (2)
11 BA17597 Counter Shaft Assembly
12 B10221-093 Seal
13 P34-4 Knob
14 BA14055 Gauge Check Assembly (includes items 61 & 62)
15 B7796-005 Gauge Check Spring
16 B6547-005 Tape Keeper Post
17 02-04488 Back Cover:
• If 16 holes - Type B
• If 17 holes - Type C
18 06-08558 Imperial Sprocket Sheave Assembly (includes item 28)
06-08559 Metric Sprocket Sheave Assembly (includes item 28)
19 DA4044 Counter Cover Assembly (includes items 53 & 54)
21 BM18849-100 Imperial Counter Assembly-Innage
BM18850-100 Metric Counter Assembly-Innage
BM19954-100 Imperial Counter Assembly-outage
BM19955-100 Metric Counter Assembly-outage
22 P14-146 O Ring
23 P10-2 Retaining Ring (2)
24 P25-16 Pinion Gear
25 B7300-005 Tape Keeper Spring
26 P14-23 O Ring Seal
27 P31-669 Binding Head Mach. Screw
28 P031-04-1697 Set Screw (for counter sprocket)
29 P10-29 Grip Ring
31 P13-20 Bushing (2)
33 02-08543 Washer
34 P030-04-822 1½” NPT Plug
35 P30-237 ½” NPT Plug (Type B- Top)
P030-04-838 3/4” NPT Plug (Type C)
36 P031-32-1661 Washer
Item Part Description
