2500 Automatic Tank Gauge
76 Installation and Operations Manual
Table 3: 2500 ATG Gauge Head Spare Parts List
Cartridge Crank Handles as provisioned as follows:
1
Handle 06-10490 fits all gauges in which the tape storage sheave has ball bearings, which
includes all cassette gauges, Type B with standard motors dated 2008 and later, and all Type C
gauges.
2
Handle BM3784 fits all gauges in which the tape storage sheave has teflon bushings, which
includes all cast iron gauges and Type B gauges with standard motors dated 2008 and earlier.
85 P1-19 Spring Crank Shaft
86 B6665-011 Crank Handle Knob
87 02-05824-011 Crank Pawl Housing
88 P20-68 Spring Pin, for Crank
89 P20-14 Roll Pin, for Crank
90 P031-03-1757 Screws for Crank Ratchet Gear
91 P31-351 Screws for Crank Ratchet Cover
92 P31-630 Screws for Crank Ratchet
93 P31-347 Hex Nut for Crank Knob
95 P031-11-1723 Bolt for Crank Knob
100 02-013223 PTFE Shim for checker
Item Part Description
