2500 Automatic Tank Gauge
82 Installation and Operations Manual
02 B5059-046 Back Cover Cap Gasket (For a transmitter)
B5059-146 Back Cover Cap Gasket - No center hole (if no transmitter)
03ci B5060-001-7 Back Cover Cap, Painted (Cast Iron Gaugehead)
04 B7415-093 Teflon Washer (Not shown - used on older Gaugeheads)
05 B8235-040 English Dial Gear
B8327-040 Metric Dial Gear
06 02-013187-046 Counter Cover Gasket
07 B8218-001 English Dial Plate (Fractional or Decimal)
B8325-001 Metric Dial Plate (30 cm Graduations) Innage/Outage
08ci BB7761 Tape Storage Sheave Assembly (Includes item 58) (Cast Iron
Gaugehead)
09 B8234-001 Dial Retainer
10 BA7763 Shaft Support Assy (2) (Type C & Cast Iron Gaugeheads)
11 BA17597 Counter Shaft/Hub Assembly
13 P34-4 Knob, Phenolic, Black
14 BA14055 Gauge Check Assembly (includes items 61 & 62)
15 B7796-005 Gauge Check Spring - 304 SS
16 B6547-005 Tape Keeper Post
17 D1895-002 Back Cover - Cast Iron (16 bolt holes)
18 DB3197 Cast Iron Sprocket Sheave Assy - English (Cast Iron Gaugeheads)
(Includes 2 # 28)
DB3930 Cast Iron Sprocket Sheave Assy - Metric (Cast Iron Gaugeheads)
(Includes 2 # 28)
19 DA4044-7 Counter Cover Assembly - Painted (includes items 53 & 54)
21 BM18849-100 English Counter Assembly
BM18850-100 Metric Counter Assembly
22 P14-146 O-Ring Seal-Viton
23 P10-2 Retaining Ring, ((2) std motors, (1) cassettes)
24 P25-16 Pinion Gear
25 B7300-005 Tape Keeper Spring
26 P14-23 O Ring Seal, Teflon
27 P31-669 Screw (for tape keeper)
28 P31-1467 (2) Set Screw (for Counter Sprocket)
29 P10-29 Grip Ring 3/8"
33 02-08543 Washer, shim
34 P030-04-822 1-1/2 NPT Plug
35 P30-237 1/2 NPT Top Plug (Type B Gaugeheads & iron)
Item Part Description
