2500 Automatic Tank Gauge
86 Installation and Operations Manual
Item Part No. Description Quantity in Kits
1
B4396-046 Back Cover Gasket
2500A (Prior to 1983)
1
02-04490-071 Back Cover Gasket
2500B (1983 - 2012)
1
02-013127-046 Back Cover Gasket
2500C (2013 and later)
1
4 B7415-093 Teflon Washer 1
5 B8235-040 Imperial Dial Gear 1 (Imperial kit only)
5m B8327-040 Metric Dial Gear 1 (Metric kit only)
6 02-013187-046 Counter Cover Gasket 1
7 B8218-001 Imperial Dial (Fractional or Decimal) 1 (Imperial kit only)
7m B8325-001 Metric Dial 1 (Metric kit only)
9 B8234-001 Dial Retainer 1
12 B10221-093 Seal 1
14 BA14055 Gauge Check Assembly 1
15 B7796-005 Gauge Check Spring 1
16 B6547-005 Tape Keeper Post 1
21 BM18849-100 Imperial Counter Assembly 1 (Imperial kit only)
21m BM18850-100 Metric Counter Assembly 1 (Metric kit only)
22 P14-146 O Ring 1
23 P10-2 Retaining ring, 5/16 SS 4
24 P25-16 Pinion Gear 1
25 B7300-005 Tape Keeper Spring 1
26 P14-23 O Ring Seal 1
27 P31-669 Binding Head Mach. Screw 1
29 P10-29 Grip Ring 1
31 P13-20 Bushing 1
33 02-08543 Washer 2
37 B4847-005 Washer 1
39 P031-05-1871 Hex Head Cap Screw 6
40 P031-01-1719 Binding Head Mach. Screw 3
42 P31-612 Hex Socket Set Screw, Cup Pt. 1
43 P031-08-1720 Counter Screw 3
44 P31-1 Washer 1
45 P31-13 Shim Washer 18
48 BA7762 Negator Motor Assy (includes items 55x2 & 56) 1
52 06-10490 Crank Handle (Not Shown) 1
To Next Page
