CANopen-Specification for CANcockpit
Error Mode Output 8-Bit (6206h)
This object indicates, whether an output is set to a pre-defined error value (see 6207
h object) in case of a message time out.
1 = output value shall take the pre-defined condition specified in 6207
h object
0 = output value shall be kept if an error occurs
Actual values can be configured with WINgauge (EEPROM parameters).
OBJECT DESCRIPTION
Index 6206h
Name Error Mode Output 8-Bit
Object Code Array
Data Type UNSIGNED8
Category Optional
ENTRY DESCRIPTION
Sub-Index 0
Description Number of Outputs 8-Bit
Access ro
Entry Category Mandatory
PDO Mapping No
Value 8
Default Value 8
Sub-Index 1
Description Error Mode Output 1 to 8
Access Ro
Entry Category Mandatory
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 2
Description Error Mode Output 9 to 16
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 3
Description Error Mode Output 17 to 24
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 4
Description Error Mode Output 25 to 32
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 5
Description Error Mode Output 33 to 40
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
