1.3 Sensors
1.3.3 Temperature Sensor for Engine Coolant
❒ Sensor installation location: At the place provided by the engine manufacturer, equipment manufacturer or car manu-
facturer in the coolant circulation system (e.g. in place of the temperature warning switch) or in the coolant hose.
❒ Sensor installation only when engine is cold.
❒ Collect the coolant running out of the system in a proper container and dispose of it in accordance with legal regulations.
max.
❒ The values mentioned in the following table for the maximum tightening tor-
que (Nm max.) refer exclusively to the load-bearing capacity of products.
Prior to using the product, it is important to ask the manufacturer of the ve-
hicle, equipment system or engine in each instance for the maximum tor-
que (? Nm max.) value for the threaded hole into which the product is to be
screwed. Non-observance of the maximum tightening torque specified for
the threaded hole in each instance can result in damage to the vehicle, en-
gine or equipment system.
❒ If the connection thread is cylindrical, a sealing washer or a sealing ring made of copper must be fitted.
❒ Following sensor installation, fill up the system with the required quantity of the compositon specified coolant.
1. Safety Instructions
Product Manual
Technische Änderungen vorbehalten Technical details subject to change
1 - 7
TU00-0736-0000002
0609
M10 x 1 10 Nm
M10 x 1.5 10 Nm
1/8 - 27 NPTF 10 Nm
M12 x 1.5 15 Nm
1/2 - 20 Gang 15 Nm
M14 x 1.25 20 Nm
M14 x 1.5 20 Nm
5/8 - 18 UNF - 3A 20 Nm
1/2 In. 20 Whit. S 20 Nm
1/4 - 18 NPTF 20 Nm
M16 x 1.5 30 Nm
M18 x 1.5 30 Nm
M20 x 1.5 30 Nm
M22 x 1.5 30 Nm
M24 x 1.5 30 Nm
M26 x 1.5 30 Nm
1/2 - 14 NPTF 30 Nm
3/8 - 18 NPTF 30 Nm
R 1/2 30 Nm
R 3/8 30 Nm
3/8 - 18 Dryseal NPTF 30 Nm
3/4 - 16 UNF-3A 30 Nm
