Technische Änderungen vorbehalten Technical details subject to change
1 - 5
TU00-0736-0000002
0609
1.3 Sensors
1.3.1 Pressure Sensor for Oil
❒ Sensor installation location: At the place provided by the engine manufacturer, equipment manufacturer or car manu-
facturer in the oil circulation system (most often in place of the oil pressure switch).
❒ Sensor installation only when engine is cold.
❒ When removing the oil pressure switch or the screw from the drilled hole for the oil pressure measuring system, collect
the oil running out of the system in a proper container and dispose of it in accordance with legal regulations.
max.
❒ The values mentioned in the following table for the maximum tightening
torque (Nm max.) refer exclusively to the load-bearing capacity of products.
Prior to using the product, it is important to ask the manufacturer of the ve-
hicle, equipment system or engine in each instance for the maximum tor-
que (? Nm max.) value for the threaded hole into which the product is to be
screwed. Non-observance of the maximum tightening torque specified for
the threaded hole in each instance can result in damage to the vehicle, en-
gine or equipment system.
❒ If the connection thread is cylindrical, a sealing washer or a sealing ring made of copper must be fitted.
❒ Following sensor installation, fill up the system with the required quantity of specified oil.
1. Safety Instructions
Product Manual
M10 x 1 30 Nm
1/8 in. BSPF 30 Nm
1/8 - 27 NPTF 30 Nm
R 1/8 DIN 2999 30 Nm
M12 x 1,5 40 Nm
M12 x 1 50 Nm
M14 x 1,5 50 Nm
1/4 in. BSPF 60 Nm
1/4 - 18 NPTF 60 Nm
3/8 - 18 NPTF 60 Nm
M16 x 1,5 80 Nm
3/8 - 18 Dryseal NPTF 80 Nm
M18 x 1,5 100 Nm
