CANopen-Specification for CANcockpit
Sub-Index 6
Description Error Mode Output 41 to 48
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 7
Description Error Mode Output 49 to 56
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 8
Description Error Mode Output 57 to 64
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
Error Value Output 8-Bit (6207h)
On condition that the corresponding Error Mode is active, device failures shall set the outputs to the value configured by this
object.
0 = Output shall be set to ‘0’ in case of fault, if 6206h object is enabled
1 = Output shall be set to ‘1’ in case of fault, if 6206h object is enabled
Actual values can be configured with WINgauge (EEPROM parameters).
OBJECT DESCRIPTION
Index 6207h
Name Error Value Output 8-Bit
Object Code Array
Data Type UNSIGNED8
Category Optional
ENTRY DESCRIPTION
Sub-Index 0
Description Number of Outputs 8-Bit
Access ro
Entry Category Mandatory
PDO Mapping No
Value 8
Default Value 8
Sub-Index 1
Description Error Value Output 1 to 8
Access Ro
Entry Category Mandatory
PDO Mapping No
Value Range Unsigned8
Default Value No
Sub-Index 2
Description Error Value Output 9 to 16
Access Ro
Entry Category Optional
PDO Mapping No
Value Range Unsigned8
Default Value No
