3.3 Satellite gauge address
Each Satellite has his fixed address. The address is defined with the Assy PCB.
The matrix of the combination of the gauge type and address:
U
Maximum 16 Satellite gauges can be connected per Master. To avoid grave system conflicts, on each address
is only one gauge allowed.
3.4 Warning Lamp inside the Satellite Gauge
All warning lamps are red except the amber level warning lamps. The WINgauge allows configuration of these warning lamps.
3.5 Tolerance
The Satellites have the pointer accuracy of ± 2.5%.
2. Functional Specification
Product Manual
Address Numbers of the Satellite gauges
00 Speedo / Tacho 1
01 Pressure Engine Oil
02 Pressure Brake 1 / Rudder / Primary air
03 Pressure Transmission Oil
04 Pressure Turbocharger / Tacho 2
05 Temperature Engine Oil
06 Temperature Transmission Oil
07 Coolant Water Temperature
08 Temperature Hydraulics Oil
09 Temperature without Symbol / Gear Oil
10 Pyrometer / Pressure Brake 2 / Turbo / Exhaust
11 Level, Fuel level 1
12 Level, Fresh Water / Cylinder Head / Position Rear Wheel
13 Level, Waste Water / Fuel Level 2 / Pressure Brake 2 (250 bar) / AddBlue / Winch
14 Voltmeter
15 Hydraulic Pressure / Ammeter / Pressure Brake 1(250 bar)
