This information is already
known from the „Add Display“
configuration.
1. Step: Overwrite the name from „General“ to
„Fuel Temperature“
4. Step: Select the appropriate Symbol for „Fuel
Temperature“ from a list of predefined, standardized
Symbols by clicking to the Symbol select button and
role up or down in the pull-down-list.
3. Step: Choose the Unit (km/h, °C, h,…) for the Display
2. Step: Select the requested Trailing digits for the
particular device. Will be visible on the Master Display.
5. Step: Enter any descriptive text which shows up
later in the Master Display.
6. Step: By selection of a Hysteresis-value an
interval which helps to stabilize the display of the
physical value in the Master Display is defined.
If a Symbol cannot be found
amongst the predefined list
of Symbols, this particular
one can be created new
through the use of the
"ICON Editor". The ICON
Editor is started up by "Edit
– ICON Editor".
This dialog is closed by
selection of another device
Master, Satellite or Display in
the "Navigation-Window"
June 2009
Training WinGauge Software
page 22
