Further Specification of the Frequency Input happens by using the
function "Configure". Required Parameters for this Configuration are,
the k-value (characteristic Value for the Frequency Input) and the max.
velocity value. The starting point will be assumed as “0” for Velocity and
Frequency. From those factors the max. Frequency value will be
calculated as well as the 8 value pairs (Hz and km/h) which are filled in
the table and are displayed as a curve.
The k-value is a very sensor specific defined value. It can however be determined by the "Calculate" -
function. To execute this function is only meaningful if it can be done in a vehicle.
June 2009
Training WinGauge Software
page 34
