Accessing Upstream and Downstream Settings
Depending on the Control Mode selected (e.g. Asymmetric mode), test settings for upstream and
downstream are also displayed
Go back to top Go back to ToC
Burst (Back-to-Back) tab:
Max Rate: The default value is 100%.
In the burst test, frames are always transmitted at the maximum rate for a given minimum and maximum burst duration.
Minimum Duration: Selectable in the range 2 to 999 seconds. Default value is 2 seconds.
This is the duration of the first burst
Maximum Duration: Selectable up to 999 seconds. The default value is 20 seconds.
This is the duration of the second burst, which must be greater than the minimum burst.
Repetitions: Selectable in the range 1 to 100. The default value is 1.
This is the amount of times that the latency test will be repeated for each test frame size
RFC 2544 Setup - Burst Upstream RFC 2544 Setup - Burst Downstream
TX130M+_e-manual_D07-00-051P_RevD00
