VeEX VePal TX130M+ - Individual Stream Results

Go back to top Go back to ToC
The Global 'Traffic' screen displays:
Frame Type of all streams
Traffic Type/s of all streams
Frame size of all streams
Throughput Results - Global Traffic Summary Throughput Results - Global Stream Delay
Go back to top Go back to ToC
9.2.3 Individual Stream Results
In the 'Per Stream' tab the following measurements are available:
Summary: Framed rate, data rate, # of bytes, total # of frames associated with each stream
Errors: Errors associated with each stream
Events: Events associated with each stream
Traffic: Traffic statistics associated with each stream
Delay: Delay associated with each stream
Rates: Rates information associated with each stream
Throughput Results - Summary Stream #1 Throughput Results - Summary Stream #2
TX130M+_e-manual_D07-00-051P_RevD00
