N O. Description
1 bA
2 PE
3 Shorting copper bar of common input configuration
4 mA
5 mB
6 mC
Pow er cab le routing m ethod
The standard cabinet supports bottom cable access only, see Figure 4.3 on the next page. If the user needs top cable access,
please choose the side cabinet option, refer to Options .
The cabling method is the same, so we just take 250kVA cabinet for example.
4 Electrical Installation
43
