12. Touch Save.
13. Touch the STATUS menu icon to see the new appearance.
To choose an existing layout, navigate to the PANEL CONTENT screen and touch the radio button beside the layout, then
touch the STATUS menu icon.
Rem ove a Layout
To delete a layout:
Log in with Administrator or Service access.
Use the Edit Icon to Customize Layout
The Vertiv™ Liebert ®EXM2 Touchscreen Control Panel layout can also be changed with the Edit icons on the screen for a
user logged-in as Operator, Administrator or Service. The Edit icon can be used to add or remove panels, resize panels,
rearrange panels and change monitored parameters.
To use the Edit icon:
1. Touch the Edit icon on the panel to be edited and hold it until a Change content button appears on the
panel (about 1 second).
Change Panel
2. Touch an icon to choose the data to be displayed in the panel (see Figure 5.13 on the facing page); choices are:
a. One-Line Run Hours.
b. Status Event Log.
c. Alarms Battery Cycle Monitor Summary.
d. Change UNIT STATUS Panel Content.
3. To change the UNIT STATUS panel’s data:
e. Touch the Edit icon on the UNIT STATUS panel and hold it until the Change Content button and X’s
appear beside the parameters.
f. Touch the X beside the parameter to be removed from the panel. The Add Parameter icon (+) will appear
in the panel if another parameter can be added. The number of parameters possible is based on whether
the Status Gauge is showing.
g. Touching the Add Parameter icon brings up a window to add parameters not already shown on the
UNIT STATUS panel.
h. Touch a parameter’s icon to add it to the UNIT STATUS panel. Resize or Remove a Panel.
4. Touch and hold the Edit icon again while the Change content button is displayed.
5. Release the icon. Resize handles will appear around the panel and a large X will appear at the top right corner.
6. Pull on a handle to resize the panel.
7. Touch the large X to delete the panel.
Rearrange Panels
8. With the resize/remove handles, touch the circle in the center of the panel and drag the panel to its new position.
5 Operator Control and Display Panel
70
