INSTALLATION CUTMASTER 10MM, 12MM
Manual 0-5230 3-1 Installation
SECTION 3:
INSTALLATION
3.01 Unpacking
1. Use the packing lists to identify and account for each item.
A. Contents List for CutMaster 10mm Plant Part No. 1-4730-6
Description Quantity
CM 10mm Power Source 1
Work cable and clamp 5m (installed) 1
Carry bag 1
SL60 Torch (Including SL60 Torch 20 ft/6.2m w/ATC, consumables
set, spare parts kit)
1
Shoulder Strap 1
Operating Manual 1
Table 3-1- Contents List for CutMaster 10mm Plant
B. Contents List for CutMaster 12mm Plant Part No. 1-4200-6
Description Quantity
CM 12mm Power Source 1
Work cable and clamp 5m (installed) 1
Carry bag 1
SL60 Torch (Including SL60 Torch 20 ft/6.2m w/ATC, consumables
set, spare parts kit)
1
Shoulder Strap 1
Operating Manual 1
Table 3-2- Contents List for CutMaster 12mm Plant
2. Inspect each item for possible shipping damage. If damage is evident, contact your distributor and / or ship-
ping company before proceeding with the installation.
3. Record Power Source and Torch model and serial numbers, purchase date and vendor name, in the information
block at the front of this manual.
3.02 Lifting Options
The Power Source includes a handle for hand lifting
only. Be sure unit is lifted and transported safely and
securely.
WARNING
DO NOT touch live electrical parts.
Disconnect input power cord before mov-
ing unit.
!
WARNING
FALLING EQUIPMENT can cause serious
personal injury and can damage equipment.
HANDLE is not for mechanical lifting.
• Only persons of adequate physical
strength should lift the unit.
• Liftunitbythehandle,usingtwohands.
Do not use straps for lifting.
• Useoptionalcartorsimilardeviceof
adequate capacity to move unit.
• Placeunitonaproperskidandsecure
in place before transporting with a fork lift
or other vehicle.
