Victor CUTMASTER - Check Regulator

Troubleshooting 6-10 Manual 0-5230
CUTMASTER 10MM, 12MM TROUBLESHOOTING
6.09 Check Regulator
1
Art # A-10293
Figure 6-7- Regulator View
Turn ON the power switch and start the test as below:
WhensolenoidvalveisON,adjusttheknob1.Ifthepressureiscontinuouslyadjustable,theregulatorisOK.
