Troubleshooting 6-4 Manual 0-5230
CUTMASTER 10MM, 12MM TROUBLESHOOTING
6.04 Case Removal
!
WARNING
Read and follow safety information in Section 6.02 before proceeding.
Remove the ten screws from the case and remove the case panel.
Art # A-10242
Figure 6-2 Case Removal View
