CUTMASTER 10MM, 12MM INSTALLATION
Installation 3-4 Manual 0-5230
26lb / 11.8kg
7" (177mm)
18.5" (469.9mm)
9" (228.6mm)
CUTMASTER
®
A
40
20
30
Art # A-10216
Figure 3-3 - Power Source Dimensions & Weight
NOTE
Weight includes torch & leads, input power cord, and work cable with clamp.
CAUTION
Provide clearance for proper air flow through the Power Source. Operation without proper air flow will
inhibit proper cooling and reduce duty cycle.
