Vigilant MX1 Operator Manual Document: LT0344
Page 11-10 8 August 2017 Issue 2.4
The status of these points is generated by specific programming in the
configuration
Point
Point Description
Description
243.1.0
Scan Fail
This point is placed into fault if the MX1 does not receive valid
replies from the LCD/keyboard.
243.1.1
Enable
This point determines whether the LCD/keyboard will be set up to
ignore or accept keypresses from the keypad. If the operate state
is true, the keypad will be enabled and accept keypresses.
243.1.2
LED Board
This point is placed into fault when the LCD/keyboard detects an
LED board fault. Not used in New Zealand.
243.1.3
Keyboard
This point is placed into fault when the LCD/keyboard detects a
fault on the numeric keypad.
243.1.4
Ext Fault
This point is placed into fault when the LCD/keyboard external
fault input has been activated.
243.1.5
Micro Test
This point is placed into fault when the LCD/keyboard micro test
fails.
243.1.6
CRC Fail
This point is placed into fault when the LCD/keyboard program
CRC check fails.
243.1.7
RAM Test
This point is placed into fault when the LCD/keyboard RAM test
fails.
243.1.8
Channel A
This point is placed into fault when communication channel A is
detected to be in fault. Currently not implemented.
243.1.9
Channel B
This point is placed into fault when communication channel B is
detected to be in fault. Currently not implemented.
243.1.10
Access Level 2
This point determines whether the menu will be in Access Level
2. If the operate state is true, menu level 2 access is enabled.
243.1.11
Alarm Buzzer
This point shows the state of the alarm buzzer on the
LCD/keyboard, which is controlled directly by internal logic. It is
also sent to any RDUs allowing the buzzer to be mimicked.
ActInput indicates that the alarm buzzer is active.
243.1.12
Fault Buzzer
This point shows the state of the fault buzzer on the
LCD/keyboard, which is controlled directly by internal logic.
ActInput indicates that the fault buzzer is active. It is also sent to
any RDUs allowing the buzzer to be mimicked.
243.1.13
LCD Fault
This point is placed into fault when the LCD/keyboard LCD fails.
243.1.14
Buzzer Disable
This point indicates as Disabled when the buzzer has been
disabled, and TestOp when the buzzer is muted.
243.2.0
through
to
243.19.0
Switch Input n
This point is placed into ActInput if switch input n on the keypad is
active.
243.20.0
through
to
243.35.0
Open Collector
Output n
This point drives the open collector output n. Its operate state can
be driven by the mapped zone's operate state or by logic.
243.36.0
FRC Monitor
This point is placed into fault when the FRC to the 26 way Switch
Input connector is removed.
243.36.1
Switch Input set 0
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 0, which contains inputs 16-18.
243.36.2
Switch Input set 1
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 1, which contains inputs 1-3.
Equipment 242
– Pseudo
Points
Equipment 243
– LCD/
Keyboard
