Document: LT0344 Vigilant MX1 Operator Manual
Issue 2.4 8 August 2017 Page 11-11
Switch Input set 2
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 2, which contains inputs 4-6.
Switch Input set 3
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 3, which contains inputs 7-9.
Switch Input set 4
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 4, which contains inputs 10-12.
Switch Input set 5
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 5, which contains inputs 13-15.
When this point is placed into the Operate state by a logic
equation the corresponding indicator on the keypad turns ON.
When this point is placed into the Operate state by a logic
equation the corresponding indicator on the keypad turns ON.
When this point is placed into the Operate state by a logic
equation the corresponding indicator on the keypad turns ON.
This point is in fault if the MX1 does not receive replies from the
RZDU.
This point is in alarm and/or fault if the MCP at the RZDU is in
alarm and/or fault. Not used in New Zealand.
This point is in fault if the battery voltage is low at the RZDU.
This point is in fault if there is a fault at the RZDU. It will be
necessary to review the fault at the RZDU itself.
This point is in fault if the battery has failed at the RZDU.
This point is in fault if the charger is out of specification at the
RZDU.
This point is in fault if the RZDU has no mains supply.
This point indicates if the Silence Alarms switch at the RZDU is
active.
This point indicates if the Evacuation switch at an RZDU is active.
Not currently supported by MX1 on an RZDU.
This point is in fault if the RZDU has failed its self-test.
Indicates a short circuit on the left hand side of the x
th
MX
Detector Loop. The point state is Fault if a short circuit is
detected between the AL+ (J1-1) and AL- (J1-2) terminals,
otherwise the point is Normal.
Indicates a short circuit on the right hand side of the x
th
MX
Detector Loop . The point state is Fault if a short circuit is
detected between the AR+ (J1-3) and AR- (J1-4) terminals,
otherwise the point is Normal.
Indicates that an open circuit fault has been detected on the x
th
MX Detector Loop. The point state is Fault if an open circuit is
detected on either the +ve wire or the -ve wire, otherwise the
point is Normal.
Equipment 244
– RZDU Points
Equipment
245
– Additional
Loop Cards
