Vigilant MX1 Operator Manual Document: LT0344
Page 1-8 8 August 2017 Issue 2.4
BUZZER
The internal buzzer pulses to indicate an alarm (if enabled – not
generally for NZ panels), and sounds continuously to indicate the
presence of a fault (for non-brigade connected NZ panels). It is silenced
by using the SILENCE BUZZER key.
NEXT
Allows the display to be stepped to the next Alarm event. It is also used
in the menus to step to the next fault, disable, etc. during a recall.
SILENCE BUZZER
Pressing the SILENCE BUZZER key will silence the MX1’s internal
buzzer. This function can be accessed from Level 1 and higher. If
another event that activates the buzzer occurs the buzzer will sound
again. The fault buzzer may also be silenced if an optional external
Silence Buzzer input is activated.
SILENCE/RESOUND ALARMS
Provides a convenient means to disable and enable the alarm devices.
Refer to “Disable Menu Options” (page 3-6).
RESET
This function can be accessed from Level 2 and higher.
Allows the operator to reset zones and points. The zone alarm and/or
fault states are reset only if the field conditions causing the alarm or fault
are cleared. With Level 3 access, this key allows the whole system to be
rebooted.
DISABLE
This function can be accessed from Level 2 and higher.
Allows an operator to disable individual zones, points, alarm devices, etc.
For further information refer to the following sections; “Disabling Zones in
Alarm” (page 2-5) and “Disabling and Enabling Points or Zones”
(page 6-6).
F1- F4
These keys are assigned functions as required according to the menu
being displayed on the LCD.
FAULTS
This function can be accessed from Level 2 and higher.
It allows the operator to view zones and points in fault, and to reset or
disable them.
Fire
Brigade
Panel
Manual
Controls
