Vigilant MX1 - Page 17

Document: LT0344 Vigilant MX1 Operator Manual
Issue 2.4 8 August 2017 Page 1-9
The yellow FAULTS LED will illuminate when one or more faults are
present. Refer to “Viewing Faults” (page 3-2) for more information.
DISABLES
This function can be accessed from Level 2 and higher. It allows the
operator to view zones, points or alarm devices that are in the Disabled
state, and to enable them.
This is not to be confused with the fire brigade panel
DISABLE key.
The yellow DISABLES LED will turn on when one or more disabled
zones or points are present.
Refer to “Viewing Disables” (page 3-4) for more information.
TESTS
This function can be accessed from Level 2 and higher.
Pressing the TESTS key allows the operator to search for active tests or
initiate a test. When initiating a test the display will show menu options
for testing zones, points, alarm devices, etc.
The TESTS LED will illuminate when one or more tests are in progress.
For more information about tests refer to “Testing Zones” (page 6-12),
“Testing Points” (page 6-16) and “Power Supply Status and Battery
Testing” (page 8-3).
MENU
Press this key to access functional options from various displays. The
options shown in any given display may vary according to the current
Access Level.
ZONE
This key provides a convenient method to enter a zone or point function.
Refer to “Displaying Zone or Point Command Menu” (page 6-2) for more
information.
NUMERIC KEYPAD
For zone and point number, decimal point and other numeric value
entries.
CANCEL
When used in menus requiring user confirmation this key permits an
operator-initiated action to be cancelled without being processed.
Press and hold this key to return the LCD to the base display.
