How do I switch between the far and near vision positions?
Tap the convergence area (#12 in the paragraph
➢ Interactions in Manual mode page 30).
The LED lights up when you are in near vision, it turns off when you are in far vision.
How do I use the cross cylinder?
Tap on cross cylinder area (#11 in the paragraph
➢ Interactions in Manual mode page 30).
Turn the cross cylinder unit according to axis verification or cylinder verification (#11 in the
paragraph
➢ Interactions in Manual mode page 30).
Tap on the flip-flap area (#11 in the paragraph
➢ Interactions in Manual mode page 30) to switch from position 1 to position 2.
Tap on central Turret Assembly area (#10 in the paragraph
➢ Interactions in Manual mode page 30) to remove the cross cylinder.
How do I use the prisms?
Tap on prism area (#7 in the paragraph
➢ Interactions in Manual mode page 30).
➢ Slide the prism area (#8), up to increase and down to decrease its value.
➢ Rotate the prism axis area (#9) to adjust its value.
Tap on central Turret Assembly area (#10 in the paragraph
➢ Interactions in Manual mode page 30) to remove the prism.
