5. PROGRAMMING
42 D-303222 PowerMaster-10/30 G2 Installer's Guide
Configuration Instructions
56:SCREEN SAVER
With Partition disabled
The Screen Saver option (when activated) replaces the status display with
“POWERMASTER-10” / “POWERMASTER-30” display if no key is pressed during more
than 30 seconds.
You can activate the Screen Saver and determine whether the status display will resume
following any key press (refresh by Key) or by entering a code (refresh by Code). If refresh
by Key is selected, the first pressing of any key (except Fire and Emergency) will produce the
status display and the second press will perform the key function. For further information, see
the User's Guide, Chapter 1, "Screen Saver Mode".
Options: OFF (default); refresh by code and refresh by key.
Notes:
1. To comply with EN requirements, "refresh by code" must be selected.
2. For Fire and Emergency keys, the first key press will produce the status display and will also
perform the Fire/Emergency function.
56:SCREEN SAVER
With Partition enabled
Certain regulations require that the system status display will not be exposed to unauthorized
persons. The Screen Saver option (when activated) replaces the system status indication on
the LCD with idle text if no key is pressed during more than 30 seconds.
You can activate the Screen Saver option and determine whether the status display will
resume following any key press (Text - by Key) or by entering a code (Text - by Code). If
Text by Key is selected, the first pressing of any key (except Fire and Emergency) will
produce the status display and the second press will perform the key function. Regarding the
Fire and Emergency keys, the first key press will produce the status display and will also
perform the Fire/Emergency function.
You can also determine that if no key is pressed during more than 30 seconds the date and
time will appear on the display. You can determine that normal display will return after
pressing the button followed by entering user code (Clock - by Code) or after
pressing any key (Clock - by Key). For further information, see the User's Guide, Chapter 1,
"Screen Saver Mode".
Options: OFF (default); Text - by code; Text - by Key; Clock - by Code; Clock - by Key.
Note: To comply with EN requirements, "refresh by code" must be selected.
5.5.7 Configuring Jamming and Supervision (Missing device)
The following table provides you with a detailed description of each option and its Options. To select an option and
change its setting (configuration) – refer to section 5.5.1.
Configuration Instructions
Define whether jamming (continuous interfering transmissions on the radio network) will be
detected and reported or not. If any of the jam detection options is selected, the system will
not allow arming under jamming conditions. The PowerMaster provides several jam detect
and reporting options to comply with the following standards:
Note: Jamming is identified by the message "system jammed" displayed on the control panel.
Detection and Reporting occurs when:
There is continuous 20 seconds of jamming
There is an accumulated 30 seconds of jamming within 60 sec.
Like EN (30/60) but the event will be reported only if the jamming
duration exceeds 5 minutes.
No jamming detection and reporting.
To comply with UL requirements, "UL 20/20" must be selected.
To comply with EN requirements, "EN 30/60" must be selected.
To comply with UK Class-6 requirements, "class 6 (30/60)" must be selected.
62:MISSING REPRT
Previously known as
Define the time window for reception of supervision (keep alive) signals from the various
wireless peripheral devices. If any device does not report at least once within the selected
time window, a “MISSING” alert is initiated.
