Visonic PowerMaster-10 G2 Installer's Guide

5. PROGRAMMING
D-303222 PowerMaster-10/30 G2 Installer's Guide 53
Option
Configuration Instructions
UL/DL modes
Define whether the downloading/uploading can be performed in Disarm mode (state) only or
in all modes (i.e. Away, Home & Disarm).
Options: in all modes (default) or in DISARM only.
Up/Download tel#
Enter the telephone number (up to 16 digits) of the UL/DL server.
Note: Only for use with control panels monitored by compatible monitoring stations. Leave
empty if not used.
(Return)
GPRS UP/DOWNLOAD
Configure the Upload/Download functionality via GPRS. The functionality is determined
through a sub-menu of the "GPRS UP/DOWNLOAD" option as shown below.
To program:
Press to enter the "GPRS UP/DOWNLOAD" sub menu and then select and configure
each of the sub-menu options as shown below. When done, press to return.
 Panel SIM Tel.#
Previously known as
"My SIM Tel.#"
Enter the PowerMaster SIM card telephone number. The PowerManage server at the
Monitoring Station sends an SMS message to this number for the panel to call back the
PowerManage server via GPRS for initiating the uploading / downloading process.
Enter the SIM card telephone number of the panel's GSM module.

1st caller ID#

2nd caller ID#
Enter the "Caller ID" (i.e. telephone number) from which Monitoring Station #1 (C.S.1) /
Monitoring Station #2 (C.S.2) calls the control panel for initiating the Up/Download process.
If the sender's Caller ID matches with the "1
st
caller ID#" / "2
nd
caller ID#", the PowerMaster
will call back the PowerManage server using "IP RCVR 1" / "IP RCVR 2" address as
configured in Section 5.6.4, options 21 and 22.
Note: Caller ID#1/ID#2 must contain at least 6 digits otherwise the process will not work.
(Return)
5.7 PGM Output
5.7.1 General Guidance
The "05:OUTPUTS" menu enables you to select events/conditions under which the PGM (programmable) output will
function and to select the internal siren or STROBE light (that will be activated according to system programming).
1
05:OUTPUS
  
PGM DEVICES
  
PGM DEVICE 01
  
MENU you wish
Enter "PGM DEVICE 01", select the menu you wish to configure (see guidance above and in section 5.2), and then
refer to the table in section 5.7.5 for configuration instructions.
Note: PGM not to be enabled in UL Listed Product.
5.7.2 Open Collector States
The PowerMaster provides an open collector output (active low) for control:
ON state (pulled to ground) = 0
OFF state:
no pullup = float
with pullup to Vcc = 1
5.7.3 Configuring a PGM device
Define which factors, including any combination of factors, will determine the PGM output.
5.7.4 Entering Daytime Limits
05:OUTPUS
  
PGM DEVICES
  
LOCKOUT TIME
Enter the "LOCKOUT TIME" menu and enter the daytime limits through which the PGM device will turn off, even when
the associated sensors are triggered.
1
In PowerMaster-10 G2, this is always available. In PowerMaster-30 G2, this is optional only when the expansion module is installed.

Visonic PowerMaster-10 G2 Specifications

General

Model	PowerMaster-10 G2
Category	Security System
Wireless Technology	PowerG
Remote Control	Yes
Event Log	1000 events
Communication	GSM, PSTN, IP
Frequency	868 MHz
Type	Wireless
Operating Temperature	-10°C to +55°C
Humidity	Up to 85% non-condensing
