APPENDIX B. Working with Partitions
D-303222 PowerMaster-10/30 G2 Installer's Guide 71
93% relative humidity, @ 30°C (86°F)
93% relative humidity, @ 30°C (86°F)
196 x 180 x 55 mm (7-5/8 x 7 x 2 in.)
266 x 201 x 63 mm (10-7/16 x 7-7/8 x 2-1/2 in.)
658g (23 Oz) (with battery)
1.44Kg (3.2 pounds) (with battery)
A6. Peripherals and Accessory Devices
GSM/GPRS, IP (future use)
GSM/GPRS, IP (future use)
Additional
wireless devices
30 detectors, 8 keyfobs, 8 keypads, 4 sirens,
4 repeaters, 8 proximity tags
64 detectors, 32 keyfobs, 32 keypads, 8
sirens, 4 repeaters , 32 proximity tags
Wireless Devices
and peripherals
Magnetic Contact: MC-302 PG2, MC-302E
PG2
Motion Detectors: Next PG2; Next K9 PG2,
TOWER-20 PG2 (not UL listed), TOWER-
32AM PG2 (not UL listed), TOWER-32AM K9
PG2 (not UL listed), TOWER-30AM PG2,
TOWER-30AM K9 PG2, CLIP PG2 (not UL
listed)
PIR Camera Detectors: Next CAM PG2;
Next CAM-K9 PG2
Smoke Detector: SMD-426 PG2, SMD-427
PG2
GSM Module: GSM-350 PG2 (optional)
Keyfob: KF-234 PG2, KF-235 PG2 (not UL
listed)
Keypad: KP-140 PG2/KP-141 PG2 (with
proximity tag), KP-160 PG2
Indoor Siren: SR-720 PG2
Outdoor Siren: SR-730 PG2
Repeater: RP-600 PG2
Gas: GSD-441 PG2 (not UL listed), GSD-442
PG2 (CO detector)
Glass-break: GB-501 PG2 (not UL listed)
Temperature: TMD-560 PG2
Flood: FLD-550 PG2
Shock: SD-304 PG2 (not UL listed)
Note: UL requires that when using remote
smoke/CO detectors and repeaters, each
detector must be within range (STRONG) of 2
repeaters at all times (for path redundancy –
UL 985).
Magnetic Contact: MC-302 PG2, MC-302E
PG2
Motion Detectors: Next PG2; Next K9 PG2,
TOWER-20 PG2 (not UL listed), TOWER-
32AM PG2 (not UL listed), TOWER-32AM K9
PG2 (not UL listed), TOWER-30AM PG2,
TOWER-30AM K9 PG2, CLIP PG2 (not UL
listed)
PIR Camera Detectors: Next CAM PG2;
Next CAM-K9 PG2
Smoke Detector: SMD-426 PG2, SMD-427
PG2
GSM Module: GSM-350 PG2 (optional)
Keyfob: KF-234 PG2, KF-235 PG2 (not UL
listed)
Keypad: KP-140 PG2/KP-141 PG2 (with
proximity tag), KP-160 PG2
Indoor Siren: SR-720 PG2
Outdoor Siren: SR-730 PG2
Repeater: RP-600 PG2
Gas: GSD-441 PG2 (not UL listed), GSD-442
PG2 (CO detector)
Glass-break: GB-501 PG2 (not UL listed)
Temperature: TMD-560 PG2
Flood: FLD-550 PG2
Shock: SD-304 PG2 (not UL listed)
Note: UL requires that when using remote
smoke/CO detectors and repeaters, each
detector must be within range (STRONG) of 2
repeaters at all times (for path redundancy –
UL 985).
APPENDIX B. Working with Partitions
Your alarm system is equipped with an integrated partitioning feature that can divide your alarm system into three
distinct areas identified as Partition 1 through 3. A partition can be armed or disarmed regardless of the status of the
other partitions within the system. Partitioning can be used in installations where shared security systems are more
practical, such as a home office or warehouse building. When partitioned, each zone, each user code and many of your
system's features can be assigned to Partition 1 to 3. Each user code is assigned with the list of partitions it is allowed
to control in order to limit access of users to certain partitions.
When partitioning is enabled, menu displays are changed to incorporate the partition feature and also each device, user,
and proximity tag has additional partitions menu, where it is assigned to certain partitions and excluded from others.
Note: When Partition Mode is disabled, all zones, user codes, and features of the control panel will operate as in a
regular unit. When partition mode is enabled, all zones, user codes, and features of the control panel are
automatically assigned to Partition 1.
B1. User Interface and Operation
Refer to the control panel User's Guide APPENDIX B. PARTITIONING for a detailed description of the user interface
(Arming/Disarming, siren behavior, show function, etc.), and APPENDIX A for keyfobs and keypads operation in
Partition Mode.
