APPENDIX A. Specifications
70 D-303222 PowerMaster-10/30 G2 Installer's Guide
PowerMaster-10 G2
PowerMaster-30 G2
by GP or equivalent.
4. 9.6V 2200 mAh, rechargeable NiMH battery
pack (special order) or equivalent.
5. 7.2V 1800 mAh, rechargeable NiMH battery
pack, p/n GP180AAH6BMX, manufactured
by GP only.
Caution! Risk of explosion if battery is
replaced by an incorrect type. Dispose of
used batteries according to the
manufacturer's instructions.
Note: For compliance with UL standards the
battery backup period shall exceed 24 hours and
12 hours for compliance with CE standards.
Time to Charge
80 % ( 13 Hrs)
80 % ( 30 Hrs) for all battery types
Optional Backup
Battery Pack
See "Backup Battery Options" above
See "Backup Battery Options" table above
Time to Charge
(optional backup
battery pack)
80 % ( 24 Hrs)
NA
Wired Detectors
Total (Sum)
Current
NA
36* mA max.
Site External Siren
Current (EXT)
NA
450* mA max @ 12.5 VDC when powered by
AC/DC (10.5 VDC when in standby mode)
Site Internal Siren
Current (INT)
NA
450* mA max @ 12.5 VDC when powered by
AC/DC (10.5 VDC when in standby mode)
* Total PowerMaster-30 G2 output current
(of INT & EXT sirens, PGM output and
detectors) cannot exceed 550 mA.
PGM
Current sink to control panel GND 100 mA
max.
Max. external DC voltage +30 VDC
Current sink to control panel GND 100 mA
max.
Max. external DC voltage +15 VDC
High Current /
Short Circuit
Protection
NA
All outputs are protected (automatic reset fuse)
A4. Communication
PowerMaster-10 G2
PowerMaster-30 G2
Communication
PSTN; GSM; GPRS; IP (for future use)
PSTN; GSM; GPRS; IP (for future use)
Built-in Modem
300 baud, Bell 103 protocol
300 baud, Bell 103 protocol
Data Transfer to
Local Computer
Via RS232 serial port
Via RS232 serial port
Report
Destinations
2 Monitoring Stations, 4 private telephones
2 Monitoring Stations, 4 private telephones
Reporting Format
Options
SIA, Contact ID, Scancom, SIA IP, Visonic
PowerNet.
Note: For UL Listed product, the
communication formats used are SIA and
Contact ID.
SIA, Contact ID, Scancom, SIA IP, Visonic
PowerNet.
Note: For UL Listed product, the
communication formats used are SIA and
Contact ID.
Pulse Rate
10, 20, 33 and 40 pps - programmable
10, 20, 33 and 40 pps - programmable
Message to Private
Phones
Tone
Tone or voice
Ring Detection
The unit does not support ring detection without
DC voltage present on the telephone lines.
The unit does not support ring detection without
DC voltage present on the telephone lines
A5. Physical Properties
PowerMaster-10 G2
PowerMaster-30 G2
Operating Temp.
Range
14°F to 120°F (-10°C to 49°C)
Note: For UL Listed product, the ambient
temperature is 32°F to 120°F (0°C to 49°C)
14°F to 120°F (-10°C to 49°C)
Note: For UL Listed product, the ambient
temperature is 32°F to 120°F (0°C to 49°C)
Storage Temp.
-4°F to 140°F (-20°C to 60°C)
-4°F to 140°F (-20°C to 60°C)

Visonic PowerMaster-10 G2 Specifications

General

Model	PowerMaster-10 G2
Category	Security System
Wireless Technology	PowerG
Remote Control	Yes
Event Log	1000 events
Communication	GSM, PSTN, IP
Frequency	868 MHz
Type	Wireless
Operating Temperature	-10°C to +55°C
Humidity	Up to 85% non-condensing
