APPENDIX E. Sabbath Mode
76 D-303222 PowerMaster-10/30 G2 Installer's Guide
D3. Understanding the Scancom Reporting Protocol Data Format
The SCANCOM data format consists of
13 decimal digits divided into 4 groups,
from left to right, as shown on the right.
Each channel is associated with a
specific event as follows:
1
st
"C": Fire
2
nd
"C": Personal attack
3
rd
"C": Intruder
4
th
"C": Open/close
5
th
"C": Alarm cancel
6
th
"C": Emergency
7
th
"C": Second alarm
8
th
"C": Trouble messages
Account
Code
aaaa
Channels
1 - 4
cccc
Channels
5 - 8
cccc
S
System Status:
no trouble, test,
low battery
- - - - - - - -
The digit in this position
conveys the status of
channel 1
The digit in this position
conveys the status of
channel 8
Scancom Data Format
D4. SIA over IP - Offset for Device User
Type
Number Range
In Hex
Example
Remarks
System reports
00
System tamper would report as 000
Normal Zones/Detectors
0-499
Zone 5 would report as 005
Keyfobs / Users /Tags
501-699
Keyfob/User number 101 would report
601
Keypads/ASU
701-799
Keypad number 8 would report 708
Sirens
801-825
Siren number 9 would report 809
Repeaters
831-850
Repeater number 4 would report 834
Expanders/Bus devices/PGM
851-875
Device number 2 would report 852
Troubles for:
GSM
Plink
Guard
876
878
879
CSM module network fail 876
901- 999
For future use
APPENDIX E. Sabbath Mode
E1. General Guidance
The Sabbath Mode allows you to use the alarm system without violating the Sabbath. The basic feature of this alarm
system is that the PIR sensors are not activated during Disarm mode.
The method of installation, as illustrated in the drawing below, is used in order to prevent transmission from the
magnetic contact device. The MC-302E device is used only as a transmitting device to report the status of the door to
the control panel. A wired magnetic contact is connected to the input of the MC-302E device and an open/close switch
is connected in parallel to the MC-302E input.
Note:
Before the Sabbath, closing the circuit neutralizes the detector’s magnet. You can use the front door without
violating the Sabbath. On the Sabbath day itself, you can open the switch to allow the door to be protected. This
operation is permitted on the Sabbath and also when the control panel is armed.
E2. Connection
1.
Enroll an MC-302E to the PowerMaster control panel (see section 5.4.2).
2.
Configure the “Input #1” setting option of the MC-302E to “Normally Closed” (refer to the MC-302E Installation
Instructions, section 2.3).
3.
Connect to the MC-302E a wired magnetic contact to be installed on the door and that is operated by
opening/closing the door (see drawing below).
4.
An open/close switch must be connected in parallel to the input of the MC-302E.
