Visonic PowerMaster-10 G2 Installer's Guide

5. PROGRAMMING
56 D-303222 PowerMaster-10/30 G2 Installer's Guide
5.8.3 Voice Box Mode
1
This mode allows you to determine whether two-way voice communication is to be sounded either via an external
speakerphone, via the control panel, or via both.
For the two-way voice communication procedure, follow the instructions below. Additional details and guidance are
provided in section 5.2.
06:CUSTOM NAMES
  
VOICE BOX MODE
Enter "VOICE BOX MODE", and then refer to the table below which provides you with the options.
VOICE BOX MODE
Define whether two-way voice communication is to be sounded either via the external
speakerphone ("VOICE BOX ONLY"), via the control panel ("NO VOICE BOX"), or via both
("VOICE BOX MIXED").
Options: NO VOICE BOX; VOICE BOX ONLY and VOICE BOX MIXED (default)
5.9 Diagnostics
5.9.1 General Guidance – "Diagnostics" Flow-Chart & Menu Options
The DIAGNOSTICS menu enables you to test your system and to verify proper operation of your PowerMaster panel,
wireless devices attached to it and the communication (GSM/GPRS) modules.
IMPORTANT! Reliable reception must be assured during the initial testing and also throughout subsequent system
maintenance. A device should not be installed in location where signal strength is "poor". If you get "poor" signal
strength from a certain device, simply re-locate it and re-test until a "good" or "strong" signal strength is received. This
principle should be followed throughout the diagnostic test procedure.
Note: For UL installations, "strong" signal strength for WL Devices is required.
The diagnostic test process is shown below.
The "07.DIAGNOSTICS" menu contains several sub-menu options, each covering a group of configurable features and
parameters related to the communication and reporting as follows (see the list in Step 3 of the chart below):
Option
Description of Option Features and Parameters
Section
WL DEVICES
Describes how to test the devices attached to the PowerMaster panel, review
devices' status and RF signal status. You can test all devices, test single device,
review devices status and review RF problems, in case of any.
5.9.2
GSM/GPRS
Describes how to test the GSM/GPRS communication module.
5.9.3
To enter the "07.DIAGNOSTICS" menu and to select and configure an option, proceed as follows:
Step 1
Step 2
Step 3
Step 4
Select "07.DIAGNOSTICS
"
Select sub-menu option
Select the diagnostics you want to perform




See
INSTALLER MODE

07.DIAGNOSTICS
WL DEVICES
TEST ALL DEVICES
5.9.2

SHOW ALL DEVICES
SHOW RF PROBLEMS
TEST ONE DEVICE
Contact sensors
Motion sensors

Repeaters
GSM/GPRS
5.9.3
5.9.2 Testing Wireless Devices
The PowerMaster enable to test the wireless devices attached to the panel. You can test all devices, one device at a
time, display devices' status and review RF problems, in case of any.
07:DIAGNOSTICS
  
WL DEVICES
  
MENU you wish
Enter the "WL DEVICES" menu, select the type of test you wish to perform (see guidance above and in section 5.9.1),
then refer to the table below which provides you with detailed explanations for each option.

Visonic PowerMaster-10 G2 Specifications

General

Model	PowerMaster-10 G2
Category	Security System
Wireless Technology	PowerG
Remote Control	Yes
Event Log	1000 events
Communication	GSM, PSTN, IP
Frequency	868 MHz
Type	Wireless
Operating Temperature	-10°C to +55°C
Humidity	Up to 85% non-condensing
