5. PROGRAMMING
50 D-303222 PowerMaster-10/30 G2 Installer's Guide
Configuration Instructions
Voice <- -> C.S.
Ringback time
Ambient level
(Return)
Master Installer only for
Send 2wv code /
Voice <--> C.S. /
Ringback time
Station (to turn the Monitoring Station from data communication to voice communication
state) by using pre-selected SIA or Contact-ID communication format only.
Voice <--> C.S.: Select the timeout for 2-way voice communication with Monitoring Stations, or
enable the Monitoring Station to ring back for 2-way voice function. This option is applicable only
after reporting an event to the Monitoring Station for listening and speaking.
Ringback Time: Define the period during which the Monitoring Station can establish 2-way
voice communication with the control panel
1
(after 1 ring), if:
A. Alarm type message was received by Monitoring Station.
B. Ring Back function was selected (see “Voice <--> C.S.” sub menu above).
Ambient Level: Select the ambient noise level of the installation. If it is a relatively noisy
environment, set it to High (default setting). If it is a very quiet environment, set to Low.
Note: Two-way voice not to be enabled on UL Listed product.
Options: don’t send (default); and send.
Options: disable (default); timeout 10/45/60/90 s; timeout 2 m; and ringback.
Note: If "ring back" is selected, you should select "disable report" for private telephone (see
Option "01:REPORT EVENTS"), otherwise the Monitoring Station will establish communication
with the control panel
1
(after an event occurrence) in the normal manner (and not after one ring).
Options: 1 (default)/3/5/10 minute(s).
Options: low (default); and high.
66:24H ZONE RPRT
Applicable in UK only
Define whether 24 hour (silent and audible) zones will function as normal 24 hour zones or as
panic zones.
Options: audibl as panic; silent as panic; both as panic; and both burglary (default).
Event Reporting Chart
To simplify the configuration of reporting system events to Monitoring Stations, the event messages are divided into 5
Event Groups as described in the following table below: Due to lack of space in the display, the following abbreviations
are used alrm, alrt, o/c” and all (i.e. all events).
Fire, CO, Burglary, Panic, Tamper
Arming AWAY, Arming HOME, Disarming
No-activity, Emergency, Latchkey
All other Trouble events not indicated above, e.g. Missing, Jamming, Communication Fail etc.
Note: "Alarms" group has the highest priority and "Alerts" group has the lowest priority.
The PowerMaster allows you also to select which event groups will be reported to each of the two Monitoring Stations.
The table below describes the available reporting options. The minus (-) symbol means "but/less/except" e.g. all(-alrt)
means all events except alerts. The asterisk () is a separator between event messages reported to Monitoring
Station 1 (C.S.1) and event messages reported to Monitoring Station 2 (C.S.2).
Available Reporting Options
Events Reported to C.S. 1
Events reported to C.S. 2
All, only if C.S.1 does not respond
All but open/close, only if C.S. 1 does not respond
Note: “all” means that all 5 Groups are reported including Trouble messages - sensor / system low battery, sensor
inactivity, power failure, jamming, communication failure etc.
